9.2.4.   Parallel Growing Neural Network Framework

Also, the parallel growing neural network framework introduced in chapter 8 was applied to the data with 500 parallel runs of the growing neural networks for each analyte. The ranking of the variables, which is combined for all analytes similar to section 9.1.2, is shown in figure 66. The second step of the algorithm (20-fold random subsampling sets) stopped after the addition of 5 variables, which are labeled in figure 66. Compared with the variable selection by the GA framework, the selection by the parallel growing network framework looks similar, but not identical. Instead of the signal at 20 s the time point 35 s is used (variation of ethanol and 1-propanol) and instead of the time point 55 s the signal at 650 s is used (main variation of 1-propanol). According to table 6, the corresponding optimized neural networks (4 hidden neurons and 1 output neuron) showed the best predictions of all methods used for this data set.

figure 66: Frequency of the variables selected in the first step of the parallel growing neural network framework

The randomization test (200 parallel runs of the growing nets) demonstrates that the parallel growing neural network framework is highly reproducible with the selection of the same 5 variables (see figure 67). When comparing figure 67 with figure 65, it is obvious that the growing neural nets are less subject to selecting random variables due to chance correlation than the genetic algorithm.



figure 67: Ranking of the variables for 50 time points and for 50 additional random variables.
